drive.web App Overview
Configured options for smarty & speedy



These options are pre-programmed units with generic solutions for key applications. The packages are a great design aid.

These generic configurations are easily edited to suit your specific installation using

savvy

with the

SFD

Signal Flow Diagram option and include the following features:
  • Detail signal flow diagram documentation

  • savvyPanel

    touch screen PC or iOS operator station configuration
  • Basic wiring drawing

smarty
smarty7 - Right Front Corner

speedy

smarty speedy
dw210 dw212 dw213 dw214 dw215 dw220 dw221 dw222 dw223 dw224 dw225
-1101 Open loop constant tension center winder (includes options 05, 06, 26) X X X X X X X X X
-1102 Closed loop dancer controlled winder (includes options 05, 06, 26) X X X X X X X X X
-1103 Closed loop loadcell controlled winder (includes options 05, 06, 26) X X X X X X X X X
-1104 Slip core winder controller (includes options 05, 06, 26) X X X X X X X X X
-1105 Speed lock with encoder feedback (includes options 05, 11, 16, 26, 42 & 45 or 46) X X X
-1106 Coordinated drive, line master controller (includes options 05, 26) X X X X X X X X X X
-1107 Controller networking for an analog/logic interface to drive (includes opts 05, 26) X
-1109 Phase lock, electronic line shaft + registration (includes opts 05, 11, 16, 26, 42 & 45 or 46) X X X
-1110 Three PID Controllers with integral reset and hold (includes options 05, 26) X X X X X X X X X X X
-1113 2 Channel pulse train follower with ratio setting (includes options 05, 26, 27) X X X X X
-1117 Encoder cyclic position w/indexing (includes opts 05, 11, 16, 26, 42 & 45 or 46) X X X
-1118 Sun tracking for solar energy sys. (includes options 05, 11, 16, 26, 42 & 45 or 46) X X X X X
