Utility
E-Mail Notification
Description Sends an e-mail when the Send parameter sees a positive-going transition. For this to work, the SMTP Server address must be set for the device. The Router IP Address and Subnet Mask typically must also be set. The subject of the e-mail will be "Notificaton". The device will make a best effort to send the e-mail; regular testing is recommended.
Availability
  • Available only in the dw2xx series products
  • Requires library: System & I/O
  • Firmware versions 0x2012 and later
savvy-SFD Graphic emailNotify
Graphic with Parameters emailNotify

Parameters

Send Input, Read-write, Boolean (signed 16-bit integer)

The e-mail is sent on a positive-going transition. A delay-off timer or similar may be connected to limit the number of e-mails sent if the source can transition rapidly.
0 = Low
1 = High
Address Internal Parameter, Read-write, E-Mail Address (US-ASCII String)

A single, valid e-mail address should be entered here.
Message Internal Parameter, Read-write, US-ASCII String (US-ASCII String)

This will be sent as the body of the e-mail message.
